ESP12F ESP8266-12F ESP 8266 12F 12 F Wifi Wireless Internet Arduino C

ESP-12F
ESP8266-12F is an enhanced version of ESP8266-12, perfect peripheral circuit, four-layer board technology, enhanced impedance matching, better signal output, whether it is stability or anti-jamming capability, PCB antenna through professional laboratory testing, ROHS certification , Have been greatly improved! For those who choose ESP-12 before, even if the product has been made it does not matter, enhanced version is fully compatible with the firmware before the pin in the ESP-12 on the basis of the addition of six IO port, SPI port leads, the development more convenient, More extensive!

– Standards Certification: FCC / CE / TELEC
– Wireless standards: 802.11 b / g / n
– Frequency range: 2.4GHz-2.5GHz (2400M-2483.5M)
– Data interface: UART / HSPI / I2C / I2S / Ir Remote Contorl GPIO / PWM
– Operating voltage: 3.0 ~ 3.6V (recommendation 3.3V)
– Working Current: Average: 80mA
– Operating temperature: -40 ~ 125
– Storage temperature: Nomal temperature
